Name：ZYS-ZK-J30 Automatic egg loader

Product Code： 615

Capacity： 30,000 eggs/hour

Function： Stack tray loading, turntable synchronized positioning, egg tray transfer, single tray conveying, egg loading and empty tray stacking

Details

The Zenyer 615 automatic egg loader includes a stack tray loading conveyor (conveyor 1), turntable, 2 lifter heads (lifter head 1 and lifter head 2), a single tray conveyor (conveyor 2) and has an empty tray stacker as well.
It transfers egg trays and load eggs with quick but gentle, suits for both pulp and plastic trays. Also, it can be flexibly integrated into existing or brand-new egg processing equipment.
It has control panel with user friendly color touchscreen and physical buttons as well to allow for easy control of the machine and access to the system.

Features:

--You can put stack egg trays (no more than 6 trays per stack) on the stack tray loading conveyor (conveyor 1) manually, the conveyor will transfer the eggs under lifter head 1, then head 1 sucks the whole tray of eggs (including the tray itself) and transfers them onto the single tray conveyor (conveyor 2).
-- When the 30-eggs tray arrives under lifter head 2, head 2 will suck 30 eggs up from the tray and load the eggs onto the roller (which is the part of the egg grader, not the part of the Zenyer 615 automatic loader).
--The empty tray will be transported to the empty tray stacker and then be stacked automatically.
-- There's a stuck egg detector on conveyor 2, if eggs are stuck on the tray (hasn't be sucked by lifter head successfully), this tray will not be stacked by tray stacker, will flow to the end of the conveyor, you can collect it from there manually.
-- It has a self-diagnosis system, which diagnoses any malfunctions that may occur.
--Ideally, connect the Zenyer 615 auto vacuum loader with the Zenyer egg grader, which makes egg loading easier and more efficient.

Model	ZYS-ZK-J30
Product code	615
Capacity	30,000~60,000 eggs/hour
Main material	Stainless steel
Power	7.43KW,
Voltage	220~240V, single phase, 50HZ Or 380~415V, 3-phase, 50HZ
People	1~2
Dimension（L*W*H）	4.47*2.33*2  M
Function	Stack tray loading, turntable synchronized positioning, egg tray transfer (5*6 egg tray), single tray conveying, egg loading (30 eggs) and empty tray stacking
